Tunnel belt type paper tube microwave drying machine

Place of Origin:
Shandong, China (Mainland)
Brand Name:
LD
Certification:
CE
Min.Order Quantity:
1 Set/Sets
Price:
US $8,890 - 11,900/ Set
Payment Terms:
paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
Supply Ability:
300 Set/Sets per Year
Contact Now


Product Description

Industrial Paper Tube Drying Machine Features:

Because microwave has rapid heating,uniform heating,save enerLD/efficient,safety/harmless,work continuously,improve working conditions LDly etc features,it’s widely used in the paper products processing of drying stereotypes bend resin agglutination etc .Apply to paper,paper tube, honeycomb cardboard,environmental protection paper bowl,egg tray,cardboard box, Kraft bag,paper yarn compound bag etc fast drying.Another application in paper products and wood pulp processing is glue adhesion and curing.This not only can use cheap adhesives made into high quality carton box,but also can’t worry about rai and cloudy trouble,and make high quality resin compound board.

Model rated input power (KVA) microwave output power (KW) expected dehydration(kg/h) expected sterilization (kg/h) reference size L*W*H(mm)
JN-12 16.8 12 12 100 7200*820*1750
JN-15 21 15 15 150 8300*840*1750
JN-20 28 20 20 250 9550*840*1750
JN-30 42 30 30 360 10680*1410*1470
JN-40 56 40 40 520 10680*1440*1750
JN-50 70 50 50 700 11810*1440*1750
JN-60 84 60 60 840 12940*1440*1750
JN-70 98 70 70 980 14070*1440*1750
JN-80 112 80 80 1120 15200*1600*1750

NOTE:We can design according to your requirements!
