Food processing machine Microwave roasting equipment/roaster oven for pistachios

Place of Origin:
Shandong, China (Mainland)
Brand Name:
LD
Min.Order Quantity:
1 Set/Sets
Price:
Negotiation
Payment Terms:
paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
Supply Ability:
300 Set/Sets per Year
Contact Now


Product Description

Specifications

Microwave roaster machine for nut
1.Fast roasting,roasting even
2.Taste good,keep nurtrition
3.Easy control,no harmless
4.CE

Food processing machine Microwave roasting equipment/roaster oven for pistachios

Application

Microwave industrial tunnel baking&puffing equipment are widely used in the peanut, sesame seeds,

wheat, melon seeds, sunflower seeds, peanuts, corn, soybeans, walnuts, almonds, chestnuts, pistachios,

cashews, filbert and dried fruit etc; and for leisure food, pachyrhizus chips, potato chips, dried

shrimps, fish maw and so on. Compared with the traditional production methods, microwave baked

foods are crispy and delicious, products particle puffed full, natural color, beautiful appearance, and

has insecticidal sterilization effect.

Characteristic of microwave roasting machine

1. EnerLD conversion efficiency high, fast heating.

Microwave oven itself, but microwave enerLD fever, make the material through materials within polarity produced molecular friction between internal heat. Make the liquid inside processed materials instantaneous warming vaporization, boosting inflation; And depend on gas expansion force make component of macromolecule substance, and become a structural degeneration areolar tissue structure characteristics, finalize the design of microporous shape more than substance.

2. when microwave baking ,sterilization effect at the same time.

Microwave sterilization is in the microwave heating and the dual role of non-thermal effect under the temperature sterilization, compared with conventional in lower temperature and very short time get satisfactory antiseptic effect. General sterilizing temperature around in 80 °C, the processing time in 3 ~ 5 minutes, and to the maximum maintain its nutrients.

3.The operation is convenient.

Microwave power and conveyor belt speed can adjust arbitrary

, both thermal inertia, but do not exist, simple, easy to open namely stop control. Improve the production environment. Microwave equipment nirvikalpa radiation, no dust, no noise, no pollution, easy to realize the food hygiene inspection standard.

4. Puffed effect is obvious.

Microwave fast heating effect, make the material internal water molecules, achieve rapid vaporization ,reach to the puffed purpose.

5. Low temperature sterilization, nutrition loss less.

Microwave sterilization is in the microwave heating and the dual role of non-thermal effect under the temperature sterilization, compared with conventional in lower temperature and very short time get satisfactory antiseptic effect. General sterilizing temperature around in 80 °C, the processing time in 3 ~ 5 minutes, and to the maximum maintain its nutrients. The reserves of vitamin C conventional heat treatment fruits and vegetables is 46% ~ 50%, microwave, can reach 60 ~ 90; Keep to vitamin A conventional heat treatment is 58 percent, and microwave treatment is to 84%, and would not affect the original flavor, is the fruit and vegetable food processing, obtain the good means green food.

Introduction of the design of microwave machine

1.Transmission System:

a. Speed of Conveying belt is adjustable.

In the transmission system, it applies frequency-converting control of speed, worm gear reducer.

b. The conveyor belt is Teflon Belt,special for microwave.

c. The deviation of belt is adjusted with Hand-movement.

2. The body of the Tunnel

a.The body of the microwave tunnel is made of Stainless Steel. In side there is one set of humidity extraction system to extract the humidity after heating.

b. To be safe, there is Automatic Power-off device while open the door of the machine.

c. The protecting case of Magnetic-pipe and transformer is made of stainless steel. On top there is one set of Heat extraction system to extract the heat enerLD generated by

working of machine.

d.The frame of machine is made of Stainless Steel pipe ,others is made of cold-rolled sheet painted.

e.One set of infrared thermometric is installed at the outlet of the tunnel to measure the temperature.

3.The controlling system

a. On the outside panel there are frequency converting speed controller, emergency stop button, Start, Stop buttons,

b. All the controlling components will be installed into one controlling box, which is at the entrance of the machine.

c.Ordinary button control system,.

d.The microwave power can be adjusted by choosing in the display text.

e. Every microwave source is an independent unit.If one is broken, the machine will not be prevented from running.

f. Every magnetron has an overheating protection device.

Technical parameter

Power supply

380V±10% 50HZ±1% three-phase five-wire

Microwave Output Frequency

2450±50MHz

Microwave input apparent power

168KVA

Microwave output power

120KW

Microwave power adjustment range

0-120KW(adjustable)

Ambient temperature

-5-40°C

Relative humidity

80%, Surrounding environment:no corrosive gas, conductive dust

and explosive gas

Overall dimension(L*W*H)

17460*1660*1750 mm

Transmission speed

0-10m/min(adjustable)

HeigLD of the inlet and outlet

60 mm

Microwave leak

accord with a country GB10436-89 standards(

Equipment safety

accord with GB-5226Electrical safety standard

accord with a country GB16798-1997 Food machinery health security index

Please note:Inlet/outlet orifice,conveyor belt size and overall dimension can be designed according to your requirements.


Welcome to enquiry!

Our company has engaged in producing and exporting microwave drying sterilization roasting machine for many years, and until now, our machine has exportes to overseas market, such as Brazil, India, Indonesia, Russia, Thailand and so on, and get high reputation of customers' long time using.

So you can be at ease about our service, and quality of our machine.
