seafood dryer/noodle dehydrator/fruit drying machine

Place of Origin:
Guangdong, China (Mainland)
Brand Name:
KINKAI
Certification:
CE ISO
Min.Order Quantity:
1 Set/Sets
Price:
US $1,000 - 8,900/ Set
Payment Terms:
paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
Supply Ability:
3000 Set/Sets per Year
Contact Now


Product Description

Shandong Leader Machinery Co.,ltd. Drying essence is take moisture away, but takes away the moisture temperature is not the most critical factor. The key for drying is depending on seafood drying machine relative humidity within certain space, Shandong Leader Machinery Co.,ltd. took advantage of the seafood dryer/noodle dehydrator/fruit drying machine dry essence, originality developed a "Closed Cycle" dryer, changed the traditional heat pump dryer "bake" to "dehumidifier”. Its several advantages was unmatched by the traditional heat pump dryer seafood dryer/noodle dehydrator/fruit drying machine.Shandong Leader Machinery Co.,ltd. Group invested 350 million for Shandong Leader Machinery Co.,ltd.. in ShanDong Province. seafood drying machine industrial is a modern high-tech enterprise focus on design and produce heat pump water heater, heat pump dryer, floor heating and Air conditioner .The application of seafood dryer/noodle dehydrator/fruit drying machine range from sanitary hot water supply, house and space heating, swimming pool heating to commercial usage. Factory area is 110,000 square meters and it is the one of the biggest heat pump seafood dryer/noodle dehydrator/fruit drying machine enterprise in China.

seafood dryer/noodle dehydrator/fruit drying machine

Do you want the food after drying is fresh and has no odor?

Do you want the vegetable died with bright in color?

Do you want the food has its own nutritional valve?

Product description

What Are KINKAI Fish Drying Equipment?

KINKAI Heat pump fish drying equipment takes advantage of the reversed Carnot principle, absorbing the heat from around and sending the heat to the materials which will be dried. This kind of dryer is mainly composed of heat pump dryer and drying chamber. This dryer will be controlled by touch screen controller, and the temperature can be adjusted. It has low electric consumption.

seafood dryer/noodle dehydrator/fruit drying machine seafood dryer/noodle dehydrator/fruit drying machine seafood dryer/noodle dehydrator/fruit drying machine

parameter

Specification of KINKAI Fish Drying Equipment

Single dryer + drying chamber
Model Unit JK03RD JK06RD JK12RD
power input KW 4.8 8.5 15.0
power supply V/PH/HZ 380V/3PH,50/60HZ 380V/3PH,50/60HZ
220V/1PH,50/60HZ
Rated current A 9.6A(380V),22A(220V) 17.0 30.0
Heating capacity KW 10.5 21.0 42.0
Cooling capacity KW 7.8 18.0 32.0
Dehumidify L/H 12.0 25.0 50.0
Max. temperature ≤75 ≤75 ≤75
Working condition 0-43 0-43 0-43

Electric shock

protection grade

Max.exhause pressure MPa 3.0 3.0 3.0
Noise dB(A) 75 75 75
Power consumption/H KWH 4.8 8.5 15.0
Electric heater KW 3.0 6.0 12.0
Blowing type / HORIZONTAL BLOWING 360°
Dimension of dryer MM 1675×860×1280 1760×1060×1280 2120×1360×1590
Weight KG 180 285 480
Buying Guides

Recommend Drying Machine+Drying Chamber

Recommend Dryer+Drying Chamber Sizes
Item Description Product Capacity Drying Chamber size
1 One unit JK03RD dryer + drying chamber 300Kg / batch 4000*2000*2200mm
2 One unit JK06RD dryer + drying chamber 600Kg / batch 6000*2800*2200mm
3 One unit JK12RD dryer + drying chamber 1300Kg / batch 6000*3000*2200mm
4 Two units JK03RD dryers + drying chamber 1200Kg / batch 7000*2200*2200mm
5 Two units JK06RD dryers + drying chamber 1500Kg / batch 10000*2800*2200mm
6 Two units JK12RD dryers + drying chamber 3500Kg / batch 10000*3000*2200mm

Warm prompt: We can make different drying chamber sizes for your reference.

Dehydrator Use for

Dry vegetables like Radish, lettuce, pumpkin, carrots, spinach, cassava etc;

Dry fruits like Apple, lemon, mango slices, dried longan, dried litchi etc;

Dry meat: fish, Sausage, jery beef, duck, ham ect;

Others it can dry noodle, wooden, stick incense, herbs, flowers ect.

Features

Features of KINKAI drying machine

√ Energy saving&Environmental protection.

Adopt close dehumidify+circulating drying type,saving operating cost;Without waste gas and waste heat pollution,low noise.

√ Running Stable,operating easily.

PLC+Touch Screen,running stable,operating easily;Adopt PLC control,can setting different drying curve, Suitable for drying different materials.

√ Second waste heat recovery technology(patent).

Adopt air to air heat exchanger dehumidify and recovery waste heat at the same time, saving energy more than 40%.

√ Exact control temperature and humidity.

According to different material setting different drying curve, the heat pump dryer can control the drying chamber temperature between 20-80℃.

√ Recovery volatilized component.

Some kinds of material contain volatilized component,In drying processing,hot and wet air will become condenser water then drain,collect the condenser water so that collect volatilized component.

Packaging & Shipping

The Packing Way

1. For heat pump dryer parts---with plywood

2. For drying chamber +trolleys

If shipped with 20ft container or 40ft container, no packing;

If shipped with LCL( less than container load), packed in plywood.

seafood dryer/noodle dehydrator/fruit drying machine seafood dryer/noodle dehydrator/fruit drying machine Company Information

We focus on the best heat pump dryers for more than ten years.

seafood dryer/noodle dehydrator/fruit drying machine seafood dryer/noodle dehydrator/fruit drying machine

Our Services

A. Technical service

1, We calculate the capacity and recommend the best models.
2, We supply you the professional refrigeration technical support and electronic technical support for your installation, debugging and operation.
3, We supply the spare parts and technical support in & after the warranty time.
4, We supply the training course to your workers at our factory if you need.


B. After-sales service
1, Technical support for your installation, operation and maintenance.
2, One year’s warranty, and you can pay for extended warranty.
3, Spare parts and technical support at most economic prices after the warranty

If you are interested in our fish drying equipment, please contact us for more information, such as catalogue, video,etc.

Crystal, Lin

Phone: +86+13723539881

Wechat : LX1452458675

WhatsApp : +86+13723539881

Add: Huadu District, Guangzhou City, Guangdong Province, P.R. China

The company Shandong Leader Machinery Co.,ltd. has sheet metal, injection molding, painting, Eva. & Cond, carton &foam, water tanks, assembly, and other advanced production line seafood drying machine. The configuration of laser cutting, CNC punching, CNC bending, automatic welding and other advanced production equipment and imported testing equipment. Shandong Leader Machinery Co.,ltd. have national standard laboratory, designed annual production 600,000 sets of various types of heat pump products seafood dryer/noodle dehydrator/fruit drying machine, the annual output value of 350 million dollars.The company has a large number of seafood drying machine technical, management and marketing personnel, combined with the group for 20 years of technology and experience, research and development series product to subvert the traditional air source products. Only to be imitated, not be exceeded! Shandong Leader Machinery Co.,ltd. are self-esteem, self-confidence, self-reliance, will certainly become the industry leader in seafood drying machine!

If you have any demand about microwave drying equipment and edible oil refining equipment, pls feel free contact us any time.
Email:sales21@ldfoodmachine.com
Whatsapp:+86 13064099546
Skype:leaderfoodmachine21
Contact:Mandy

NOTE:We can specially design the machine according to your production's features.
