Industrial Continuous Microwave Drying Machine For Red Rose Flower Features:
1 Application:
Comparing to ordinary equipment, efficiency can be increased 80%,speed is eigLD times.
This machine fits for drying and sterilizing powder ,granular, sheet-like or gel-like food ,and additive, flavoring, medicine, raw material of herbal medicine, nutritional health products, agriculture & sideline products, non-fried(or oil-saving)instant noodles, noodles, rice powder noodles, soy products, beef jerky, preserved meat, dried fish ,tea, tobacco and so on; and for drying, peeling and baking almond, peach kernel, groundnut kernels, chestnut and so on; and for puffing of leisure food ,pachyrhizus chips, potato chips, dried shrimps, fish maw and so on; and for sterilizing and oral liquor, pickles, a variety of small packaging food ;and for drying beans; and for thawing the frozen fish ,poultry; and for drying and desulfurating and deoxidizing the metallurgical chemical products; and for drying printing and dyeing products, ceramics, glass, chemical fiber, cotton yarn, wood, leather, bamboo products, insulation materials, building materials, cork, alveolate cardboard, corrugated ,and so on.
2 Principle of microwave heating
Microwave means electromagnetic wave with the frequency between 300 MHZ and 300 GHZ,the water molecule of the material to be heated is polar molecule,under the effect of quick change of the high electromagnetic wave,resulting the motion and mutual friction of polar molecules,changing the microwave enerLD into heat enerLD,and increasing the temperature of the heated material and resulting in the whole process of heating and puffing,so as to reach the purpose of heating.
3 Features of microwave heating
1. homogeneous and quick heating
microwave has penetrability and changes with the frequency,the depth of penetration normally from several mm to tens of cm,both the outside and inside of the material can be heated at the same time,therefore avoiding the phenomenon of overheating of the outside while the inside uncooked.Microwave heating changes the heated object to be the heating object,no heat conduction will be necessary.It takes short time for the poor heat conductivity material to reach the heating temperature.The efficiency will be increased LDly by using the microwave,and also the productivity and the quality.
2. Power saving and high efficiency
Material containing water can easily absorb the microwave and be heated,thereby there is almost no loss except the loss during the transportation,therefore high heating effect with low power consumption.
3. Mold proofing,sterilization and keeping freshness
Microwave heating has both heat effect and biological effect,can sterilize and proof mold in lower temperature.Because of the rapidly heating within short time,microwave heating can mostly save the activity,color and nutritious parts of the material.
4. Advanced technoloLD with auto-control
The heating and the termination can be realized by the control of the power of the microwave,there will be no thermal lag.It can be automatically controlled by control panel.
5. Selectivity of heating
Microwave has different functions for material with different dielectric properties,this is beneficial to heating process,because water molecule absorb microwave the LD.The part containing high water absorbs more microwave power than the one containing the less water,this is the selectivity of the microwave .While heating wood and paper,this feature can be used to heat and dry homogeneously.Please pay attention that some material will absorb the microwave better at higher temperature,the positive feedback causes the temperature of this material to increase dramatically.It’s necessary to set reasonable heating process.
6. Safety and harmless,the improvement of working environment
The microwave can be controlled in the heat conducting room made of metal and waveguide tubes,so there will almost be no leakage of microwave,no the harm of radiation and the disposal of harmful gas,no waste heat and dust,thus LDly improving the working environment and intensity of labour.
4 Technical parameters:
Power supply |
380V±10% 50HZ±1% three-phase five-wire |
Microwave Output Frequency |
2450±50MHz |
Microwave input apparent power |
≤42KVA |
Microwave output power |
≥30KW |
Microwave power adjustment range |
0-30KW(adjustable) |
Ambient temperature |
-5-40°C |
Relative humidity |
≤80%, Surrounding environment:no corrosive gas, conductive dust and explosive gas |
Overall dimension(L*W*H) |
10680*1440*1750 mm |
Transmission speed |
0-10m/min(adjustable) |
HeigLD of the inlet and outlet |
60 mm |
Microwave leak |
accord with a country GB10436-89 standards( |
Equipment safety |
accord with GB-5226Electrical safety standard accord with a country GB16798-1997 Food machinery health security index |
Please contact me to talk more details!
NOTE:We can design according to your requirements!
